Euromex iScope Series Binocular Compound Microscope with E-plan Objectives

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

Euromex iScope Series Binocular Compound Microscope with E-plan Objectives

iScope - A masterpiece in microscopy

The iScope IS1152-EPL is highly suitable for Life and Biomedical Sciences, high schools, universities but also for routine medical applications. Besides the brightfield contrast method, configurations for phase contrast, cardioid mirror darkfield, basic polarization and several epi- illumination sources for fluorescence applications can be used.

Features:

  • EWF 10x/20mm eyepieces
  • Binocular model
  • Quintuple reversed nosepiece
  • 156 x 138mm mechanical stage
  • 3 W NeoLED Kohler illumination
  • iCare sensor for energy saving
  • CSS - Cable Storage System

    • Specifications:

    EYEPIECES

  • Extended Wide Field EWF plan 10x eyepieces with 20mm field of view and adjustable diopter on the left eyepiece

    • HEAD

  • Binocular Siedentopf type heads with 30 degree inclined tubes. Interpupillary distance from 48 to 76mm
  • A unique rotating system allows the ergonomic positioning of both tubes in a high (431mm) and in a low position (397mm)

    • NOSEPIECE

  • Revolving quintuple reversed nosepiece for max. five objectives

    • STAGE

  • 156 x 138mm stage equipped with integrated 79 x 52mm X-Y mechanical stage

    • CONDENSER FOR BRIGHTFIELD

  • The standard height adjustable Abbe N.A. 1.25 condenser for brightfield accepts sliders with phase annuli suitable for plan phase 10x/20x or S40x/S100x oil immersion IOS objectives for economical phase contrast. With magnification indication.

    • FOCUSING

  • Coaxial coarse and fine adjustments, 200 graduations, 1 μm per graduation, 200 μm per rotation, total travel range is approximately 24mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustments are equipped with friction control.

    • ILLUMINATION

  • The innovative NeoLED design offer larger apertures, allowing the optical system of the iScope microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics. Other benefits of the NeoLED is the low energy consumption, no heating and a long operating lifetime.

    • ICARE SENSOR

  • The unique iCare Sensor is developed to avoid unnecessary loss of energy. The illumination of the microscope automatically switches off shortly after microscopists step away from their position.

    • CSS - CABLE STORAGE SYSTEM

  • iScope allows users to easily insert the power cable into the back of the instrument, which enables easy storage. The integrated carrying grip at the back of the microscope ensures safe transportation of the microscope.

    • PACKAGE CONTENT

  • Supplied with power cord, dust cover, a spare fuse and user manual. All packed in polystyrene boxes.
    • $376.60

    Original: $1,076.00

    -65%
    Euromex iScope Series Binocular Compound Microscope with E-plan Objectives—

    $1,076.00

    $376.60

    Product Information

    Shipping & Returns

    Description

    iScope - A masterpiece in microscopy

    The iScope IS1152-EPL is highly suitable for Life and Biomedical Sciences, high schools, universities but also for routine medical applications. Besides the brightfield contrast method, configurations for phase contrast, cardioid mirror darkfield, basic polarization and several epi- illumination sources for fluorescence applications can be used.

    Features:

  • EWF 10x/20mm eyepieces
  • Binocular model
  • Quintuple reversed nosepiece
  • 156 x 138mm mechanical stage
  • 3 W NeoLED Kohler illumination
  • iCare sensor for energy saving
  • CSS - Cable Storage System

    • Specifications:

    EYEPIECES

  • Extended Wide Field EWF plan 10x eyepieces with 20mm field of view and adjustable diopter on the left eyepiece

    • HEAD

  • Binocular Siedentopf type heads with 30 degree inclined tubes. Interpupillary distance from 48 to 76mm
  • A unique rotating system allows the ergonomic positioning of both tubes in a high (431mm) and in a low position (397mm)

    • NOSEPIECE

  • Revolving quintuple reversed nosepiece for max. five objectives

    • STAGE

  • 156 x 138mm stage equipped with integrated 79 x 52mm X-Y mechanical stage

    • CONDENSER FOR BRIGHTFIELD

  • The standard height adjustable Abbe N.A. 1.25 condenser for brightfield accepts sliders with phase annuli suitable for plan phase 10x/20x or S40x/S100x oil immersion IOS objectives for economical phase contrast. With magnification indication.

    • FOCUSING

  • Coaxial coarse and fine adjustments, 200 graduations, 1 μm per graduation, 200 μm per rotation, total travel range is approximately 24mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustments are equipped with friction control.

    • ILLUMINATION

  • The innovative NeoLED design offer larger apertures, allowing the optical system of the iScope microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics. Other benefits of the NeoLED is the low energy consumption, no heating and a long operating lifetime.

    • ICARE SENSOR

  • The unique iCare Sensor is developed to avoid unnecessary loss of energy. The illumination of the microscope automatically switches off shortly after microscopists step away from their position.

    • CSS - CABLE STORAGE SYSTEM

  • iScope allows users to easily insert the power cable into the back of the instrument, which enables easy storage. The integrated carrying grip at the back of the microscope ensures safe transportation of the microscope.

    • PACKAGE CONTENT

  • Supplied with power cord, dust cover, a spare fuse and user manual. All packed in polystyrene boxes.
